Tascam Portacapture X6

Specificatii tehnice:

• microSD card (64 MB – 2 GB)
• microSDHC card (4–32 GB)
• microSDXC card (48–512 GB)

• WAV (BWF): 44.1/48/96 kHz, 16/24 bit or 32 bit float
• MP3: 44.1/48kHz, 128/192/256/320 kbit/s
• Canale de intrare: 4 (maximum)
• Track-uri de intregistrare: 6 (4 tracks + stereo mix)

Intrari audio analogice

Intrari microfon 3–4 (balansat) XLR-3-31; 6.3-mm TRS

• Impedanta de intrare: ≥2.2 kΩ
• Nivel maxim de intrare: +2 dBu
• Nivel minim de intrare: −75 dBu

Intrari Line 3–4: XLR-3-31, 6.3-mm TRS

• Impedanta de intrare: ≥9 kΩ
• Nivel maxim de intrare: +24 dBu
• Nivel minim de intrare: −53 dBu

MIC/EXT IN (nebalansat): 3.5-mm mini jack

• Impedanta de intrare: 10 kΩ (plug-in power off); 1.8 kΩ (plug-in power on)
• Nivel maxim de intrare: 0 dBV
• Nivel minim de intrare: −67 dBV

Iesiri audio analogice: Iesire linie (LINE OUT, nebalansat): Jack de 3,5 mm:

• Impedanta de iesire: 200 Ω
• Nivelul nominal de iesire: −14 dBV
• Nivelul maxim de iesire: +6 dBV
• Iesire casti: Jack de 3,5 mm
• Putere maxima: 45 mW + 45 mW (THD+N: ≤0,1%, 32 Ω)
• Difuzor incorporat: 0,4 W (mono)

Performanta audio

• Zgomot de intrare echivalent (EIN, intrari microfon 3-4): ≤−125 dBu

Raspuns in frecventa (intrari 3-4 PCM)

• Fs 48 kHz: 20 Hz – 20 kHz, +0/−0.3 dB (JEITA)
• Fs 96 kHz: 20 Hz – 40 kHz, +0/−0.7 dB (JEITA)

Gama dinamica

• Intrari 3-4 la date PCM: ≥112 dB (48/96 kHz)
• Raport S/N (20 kHz SPCL LPF, ponderat A)

Intrari 3-4: 112 dB (48/96 kHz)

MIC / EXT IN

• 103 dB (48 kHz)
• 105 dB (96 kHz)

Raport total de distorsiune armonica (THD+N)

• Intrari 3-4 (LINE IN) la datele PCM: 0.008 %
• Intrari 3–4 (MIC IN) la datele PCM: 0.006 %

Sursa de alimentare si alte specificatii:

• Alimentare: 4 x baterii AA (alcaline, Ni-MH sau litiu-ion) / Alimentare USB de la PC / Adaptor AC (TASCAM PS-P520U, vandut separat)
• Consumul de energie: 7,5 W (maxim)
• Display: Ecran tactil LCD full-color de 2,4 inchi
• Dimensiuni: 75 × 174 × 37 mm
• Greutate: 365 g (cu baterii) / 265 g (fara baterii)
